Budget ✨ ORTUR Laser Master 2 Pro S2 LF 5.5W Laser Engraver Cutter, 10,000mm/min, Flame Detector, Emergency Stop, 32Bit 👩 Motherboard, Engraving Area 400mm*400mm 🔥
Original price was: $299.00.$96.99Current price is: $96.99.
- Buy quality, buy with us.
- Free 1 year warranty period
- Service with a smile, always online.
- Quick responses, top-notch service.
Highlights
Ultrafine Laser Point & Powerful Laser Module
This laser engraver comes with the latest FAC laser technology for compressed laser point, the focal point is 0.17*0.25mm, more focused the energy. This allows the engraving or cutting to be much stronger. The output power of the laser module reaches 5-5.5W. It can cleanly cut 5mm thick wood in one pass, and the engraving speed can be as high as 10000mm/min.
32-Bit Motherboard
ORTUR Laser Master 2 PRO-S2-LF is built with 32-Bits MCU, which has a much higher frequency than 8-Bits MCU, arithmetic speed is faster, the operation is smoother, the engraving & cutting precision is higher.
Offline Control Box
You could convert the pictures into G-code files and save them in the TF card, then, insert the TF card into the Ortur offline control box to let the machine engrave offline. You could also use the WIFI function of the offline control box to replace the USB cable to connect the computer and laser engraver.
Compatible with Windows/MAC/Linux System
ORTUR Laser Master 2 PRO-S2-LF is compatible with free engraving software LaserGRBL and paid LightBurn software. The engraving file format supports SVG/DXF/JPG/JPEG/PNG/BMP/TIF/CR2, etc.
Specification
| General | Brand: Ortur Type: Laser Engraver Model: Laser Master 2 Pro S2 LU2-4 20W LF Color: Black |
| Specification | Motherboard: OLM-PRO-V10 Motherboard – 32Bits MCU Firmware: OLF-V180 Series Firmware Safety Features 1.Active Position Protection, 2.Exposure Duration Detection and Limitation, 3.Laser Beam Safety Guard. 4.Flame Detector 5.Emergency Stop Button 6.Power Control System Add-ons: 1.Ortur Offline Controller 2.Adjustable Z-axis Lifting Device 3. Enclosure Frame Materials: Aluminum Profile + Powder Coated Steel Motors: NEMA 17 Stepper Motors Mechanical Precision: Y:12.5um X:12.5um Pixel Accuracy: Adjustable – (Default: 300 DP; roughly0.81um Pixel Accuracy) Engraving Area: 400mm*400mm Available Laser Modules: LU2-4-SF 24V Short Focus Laser Module (Electric Power: 20W, Luminous Power: 4,500-5,500mw) Wave Length: 445±5nm Focus: Fixed Focus Default Focal Length: 50mm (from the heat sink to the object) Control Mode: PWM Power Rate: S0-S1,000 Engraving Speed: 0-10,000MM/Min Baud Rate:115200 – 921600 (Default: 115200) Computer OS: Win XP, Win 7, Win 8, Win 10 (LaserGRBL) Mac and Linux (LightBurn) Control Softwares: LaserGRBL (free), LightBurn (Paid Software) Input Format: JPG, JPEG, PNG, BMP, SVG, etc. Available Materials of Engraving: Wood Board, Paperboard, Black Acrylic, Leather, Food, Stainless Steel, Power Coated Metal, etc. Available Materials of Cutting: Wood Board, Paperboard, Black Acrylic, Leather, Felt Cloth, Dark Color Plastic Sheet (Melt), etc. Input Voltage: 100-240V 50/60Hz Power Adapter Output: 24V/2A Operating Temp: -20°C-50°C |
| Weight & Size | Product Weight: 3.5Kg Package Weight: 4.6Kg Product Size(L x W x H): 60*57*18.9cm Package Size(L x W x H): 66*25*11cm |
| Package Contents | 1 x Ortur Master 2 Pro S2 LU2-4 20W LF Laser Engraving Machine 1 x User Manual |
| Option | LU2-4 SF, LU2-4 LF |
|---|
