Wholesale 💯 Geeetech Alkaid 6.08inch 2K LCD Resin 3D Printer, 3.5-inch Touch Screen, UV Photocuring, Quick FEP Replacement, 82*130*190mm 💯

Highlights

6.08 inch 2K Black and White Forming Screen

Compare with the color screen, the black and white screen has a higher light transmittance and a longer service life. What’s more, 2k resolution greatly improves the printing accuracy, which makes the X/Y accuracy can reach 0.05mm.

Larger Printing Size

82x130x190 mm, to meet your multifarious imagination and creations

Z-axis Linear Rail

In order to improve the printing accuracy and quality, the Z-axis of Alkaid adopts a high-cost linear rail that has high rigidity, high load, automatic self-aligning and absorbs the assembly error, which can effectively improve the overall printing quality of the 3D printer.

Professional UV-blocking Cover

ALKAID transparent cover contains the anti-UV element, which can effectively filter UV light of 405nm wavelength, and the blocking rate is up to 99.96%. The cover can not only ensure the printer UV light does not leak, but also ensure the external UV light does not affect the printer’s normal work.

New Generation Of Matrix Light Source

The light source adopts 15 pieces highlight power quartz lamp beads, combined with the matrix lens which is made of professional optical materials, can make the UV irradiation on the LCD screen more even and higher the intensity, hence effectively improving the printing speed and accuracy.

Quick FEP Replacement Design

For your convenience to change the release film, ALKAID redesigned the release film fixing structure. Compared with the previous generation of fixing methods, you only need to tighten 14 screws to complete the release film exchanging simply and quickly.

Ergonomic Design

The control panel of the printer adopts an ergonomic design. The large tilt Angle of the control panel enables the users to operate the machine more comfortably than the machines from other manufacturers.

Efficient Heat Dissipation System

Alkaid innovatively integrates the UV lamp beads at the bottom aluminum substrate of the machine, which can larger the heat dissipation area. Combined with the cooling fan, the temperature of the lamp board can be reduced effectively and extend the service life of the UV lamp beads.

8x Anti-aliasing

Alkaid supports up to 8-grade anti-aliasing, which can effectively improve the surface finish of the printed object.



Specification

General	Brand: Geeetech Type: Light Curing Resin 3D Printer Model: Geeetech Alkaid  Color: Black
Specification	Printing Parameter Printing Technology: LCD Light Curing Surface Forming Technology Printing Size: 82x130x190 mm XY Resolution: 0.051 mm LCD Size: 6.08 inch LCD Resolution: 2560×1620 Pixels Z-axis Precision: 0.001 mm Layer Thickness: 0.01~0.2 mm Printing Speed: 30 mm/h UV Lamp Rated Power: 45 W Resin: 405 nm Wavelength Ultraviolet Resin Slicer Software: CHITUBOX File Type: CTB Working Environment Temperature: 10 °C~35 °C Working Environment Humidity: 30%~70% Electrical Parameter Power Adapter: Input: 100V~240V, 50/60Hz, Output: 12V/5A Connectivity: USB Touch Screen: 3.5-Inch Full-color Touch Screen LCD Screen Resolution: 2K Forming Screen
Weight & Size	Product Weight: 4.2 kg Package Weight: 8 kg Product Size(L x W x H): 28.6×22.6×37.2 cm Package Size(L x W x H): 35.3×29.3×46.4 cm
Package Contents	1 x Geeetech Alkaid Light Curing Resin 3D Printer 1 x User Manual
