Best reviews of 🎉 ATOMSTACK A5 M50 Pro Laser Cutter Engraver, 5-5.5W Optical Power, 40W Electric Power, Fixed Focus, Quadruple Lens Compression Spot, Offline Engraving, Cut 20mm Wood, 410x400mm 👍

Highlights

ATOMSTACK A5 M50 PRO is newly upgraded to improve the cutting strength. Compared with ATOMSTACK A5 M50 cutting 15mm wood, the A5 M50 PRO can cut 20mm wood. ATOMSTACK A5 M50 PRO supports offline engraving, you can carry out engraving work anytime and anywhere without being restricted by the computer.

Quadruple Lens Compression Spot
The A5 M50 Pro laser cutter and engraver machine adopts 4-fold lens group collimation and focuses technology, the optical power is 5-5.5W, and the laser focus area is reduced to 0.08*0.08mm. The high-density laser can easily cut 20mm thick wooden boards, and 15mm black acrylic; can directly engrave mirror stainless steel metal and ceramics, and can achieve the effect of a 100W CO₂ laser engraving machine.

Support Offline Engraving
It configures the terminal control panel and supports offline engraving, so you can carry out engraving work anytime and anywhere without being restricted by the computer.

Eye-protection Flame-retardant Filter Panoramic Glass
The flame-retardant filter panoramic glass can filter 97% of the ultraviolet light, which plays a very good role in protecting your eyes. You and the people around you do not need to wear goggles, you can also clearly watch laser engraving.

Perfectly Compatible System
The machine can be compatible with various mature engraving software, such as LaserGRBL, LightBurn, support Win XP / Win 7 / Win 8 / XP / Win 10 / Win 11, and also support Mac system (LightBurn); engraving file format supports NC, BMP, JPG, PNG, DXF, etc.
High-performance Fixed-focus Laser
With fixed-focus laser technology, the new laser focal spot is 50% smaller than other ordinary lasers and combines precision engraving and high-energy cutting at the same time.

Smart Limit Switch Design
Limit switches are installed on both X-axis and Y-axis. When the engraving machine stroke is at its maximum, the limit switch will be automatically triggered to protect the laser and avoid collisions.

Easy Assembly
The all-aluminum alloy anodized structure design makes the machine more durable and improves the accuracy of engraving. The entire structure has been designed for quick assembly, and the assembly can generally be completed within 10-20 minutes.

More Features
It has an emergency stop button which can stop the machine at any time if an unexpected situation occurs.
The modular design of the body mechanism makes you can get a 410*850mm super large engraving size by only replacing the frame components.
There are precise scale lines on the X-axis and Y-axis to facilitate quick length measurement.



Specification

General	Brand: ATOMSTACK Type: Laser Engraving Machine Model: A5 M50 Pro
Specification	Item Model Number: A5 M50 Pro Engraving Area: 410*400mm Carving Materials: Wood, bamboo, cardboard, plastic, leather, PCB board, aluminum oxide, non-reflective Electroplating layer and paint surface layer metal, 304 mirrors stainless steel, glass, ceramics, cotton cloth, slate Cutting Material: Cardboard, non-woven fabric, wood board, acrylic, some thin plastic board, sponge Electric Power: 40W Laser Output Power: 5-5.5W Wave Length: 445 ± 5nm Engraving Accuracy: 0.01mm Focusing Method: fixed focus laser, no need to focus Laser Protective Cover: Protect the user’s eyes and prevent pets from grabbing the laser spot. Operating Software: LaserGRBL, supports Win XP / Win 7 / Win 8 / XP / Win 10 / Win 11 system; LightBurn, supports Windows/Mac OS/Linux Input Format: NC, BMP, JPG, PNG, DXF, etc. Data Transmission Method: USB connection Input Voltage: AC100-240V, 50/60Hz Output Voltage: DC12V, 5A Others: Emergency stop button; Stopper, Reset switch; The laser sintering temperature is up to 800 – 850 Celsius; replace the frame components, Expandable engraving size to 410*850mm with Extension kit (need to be purchased additionally)
Weight & Size	Product Weight: 4.3kg Package Weight: 6.1kg Finished Engraver Size(L x W x H): 56.1×65.8×26.5cm Package Size(L x W x H): 59x34x12.2cm
Package Contents	2 x Support Beam 1 x Y-axis Right Slide Rail 1 x Y-axis Left Slide Rail 1 x X-axis Rail 3 x Foot Bracket 1 x Laser Head 1 x Connecting Plate 1 x Control Box 1 x Display Screen 1 x Power Adapter 1 x Power Cable 1 x Synchronous Belt 1 x Metal Mat Board 1 x Fixed Focus Film 1 x Mounting Screws 3 x Wood Chips 3 x Acrylic Sheet 1 x HDMI Cable 1 x USB Card and Card Reader 1 x Toolkit 1 x Wire Tie 1 x Brush 1 x USB Cable 1 x Dust-free Cloth 1 x User Manual
